Low-E Glass
High-performance architectural glass designed for modern energy-efficient buildings.
Low-emissivity coatings reduce heat transfer, improve thermal insulation and optimize
solar control while maintaining excellent natural daylight transmission.
Certified
Product Overview
Advanced Glass for Energy Efficient Buildings
Low-E Glass (Low Emissivity Glass) is a high-performance coated glass
with a microscopically thin metallic oxide layer applied to the surface.
The coating reduces infrared heat transfer while allowing high visible
light transmission, creating comfortable indoor environments with reduced
energy consumption.
- Excellent thermal insulation performance
- Reduces solar heat gain and cooling costs
- Maintains high visible light transmission
- Ideal for curtain walls, facades and energy-saving windows
- Available in single silver, double silver and triple silver coatings
Why Choose Us
Key Benefits
Solar Control
Advanced coating technology reduces solar heat gain,
helping buildings maintain comfortable indoor temperatures
and lower cooling energy consumption.
Thermal Insulation
Low emissivity coating minimizes infrared heat transfer,
improving building envelope performance during both
hot summers and cold winters.
Natural Daylight
High visible light transmission creates bright interior
spaces while reducing dependence on artificial lighting.
Architectural Design
Compatible with modern curtain walls, facades,
commercial buildings and high-performance glazing systems.
Processing Flexibility
Available for tempering, laminating and insulating
glass production to meet different project requirements.
International Standards
Produced according to EN 1096, ASTM C1376,
GB/T 18915 and other global architectural glass standards.
Technical Data
Product Specifications
Standard Low-E glass configurations. Customized coating performance,
glass thickness and processing options are available for different
architectural projects.
| Parameter | Standard Range | Notes |
|---|---|---|
| Glass Thickness | 4 mm – 19 mm | Single glass, IGU and laminated configurations |
| Coating Type | Single Silver / Double Silver / Triple Silver | Different solar control and thermal performance levels |
| Emissivity (Low-E Value) | ≤0.15 – ≤0.03 | Depends on coating structure |
| Visible Light Transmission | 30% – 80% | Available in different appearance options |
| Solar Heat Gain Coefficient | 0.20 – 0.70 | Optimized for different climate zones |
| Maximum Size | Up to 3300 × 13000 mm | Subject to glass type and processing equipment |
| Standards | EN 1096, ASTM C1376, GB/T 18915 | CE, CCC and IGCC available |
Applications
Where Low-E Glass Excels
Curtain Walls
Energy-efficient glazing solutions for high-rise buildings,
commercial towers and modern architectural facades.
Windows & Doors
Improves insulation performance of residential,
villa and commercial window systems.
Commercial Buildings
Ideal for offices, shopping malls, hotels and
green building projects requiring energy efficiency.
Green Buildings
Supports sustainable architecture and helps meet
modern energy-saving building requirements.
Manufacturing
Precision Coating Process
Float glass is carefully inspected, cleaned and prepared
before entering the coating process.
Advanced vacuum coating technology deposits
ultra-thin metallic oxide layers onto glass surfaces.
Optical performance, coating uniformity and
thermal properties are tested according to standards.
Low-E glass can be further processed into tempered,
laminated or insulated glass units for global projects.
Ready to Start?
Need Low-E Glass for Your Project?
Energy-efficient glazing solutions for curtain walls,
windows and modern architectural projects.
Contact Tianhou Glass for technical datasheets,
samples and competitive quotations.
